Product Overview
| Key specifications | |
|---|---|
| Model Number | S5-GR1P2K-M |
| Width (mm) | 310 |
| Height (mm) | 373 |
| Length (mm) | 160 |
| Weight (kg) | 7.4 |
| Product Specifications | |
|---|---|
| Maximum Generator Power | 2600 Wp |
| Warranty | 5 |
| Degree of Protection | IP65 |
| Maximum Efficiency | 97.1% |
| Maximum Output Current | 10.5 A |
| Operating Temperature Range | -25 to +60°C |
| Noise Emission | - |
| Nominal AC Voltage | 330 V |
| Night-time consumption | < 1 W |
| Cooling | Passive/Natural Air Cooling |
| Display via Smartphone, Tablet, Laptop | - |
| Interfaces | Ethernet | WLAN | RS485 |
| Protection Class | - |
