Product Overview
| Key specifications | |
|---|---|
| Model Number | X1-3.6K-S-D(L) |
| Width (mm) | 267 |
| Height (mm) | 328 |
| Length (mm) | 126 |
| Weight (kg) | 8.3 |
| Product Specifications | |
|---|---|
| Maximum Generator Power | 3680 Wp |
| Warranty | 5 |
| Degree of Protection | IP66 |
| Maximum Efficiency | 98% |
| Maximum Output Current | 16 A |
| Operating Temperature Range | -30 to +70°C |
| Noise Emission | 25 dB (A) - 50 dB (A) |
| Nominal AC Voltage | 220 / 230 / 240 V |
| Night-time consumption | < 1 W |
| Cooling | Passive/Natural Air Cooling |
| Display via Smartphone, Tablet, Laptop | Yes |
| Interfaces | WLAN | RS485 |
| Protection Class | - |
