Product Overview
| Key specifications | |
|---|---|
| Model Number | X1-MINI-3.0K-G4 |
| Width (mm) | 297 |
| Height (mm) | 206 |
| Length (mm) | 120 |
| Weight (kg) | 5.2 |
| Product Specifications | |
|---|---|
| Maximum Generator Power | 3300 Wp |
| Warranty | 5 |
| Degree of Protection | IP66 |
| Maximum Efficiency | 98% |
| Maximum Output Current | 15 A |
| Operating Temperature Range | -25 to +60°C |
| Noise Emission | < 25 dB (A) |
| Nominal AC Voltage | 220 / 230 / 240 V |
| Night-time consumption | < 1 W |
| Cooling | Passive/Natural Air Cooling |
| Display via Smartphone, Tablet, Laptop | Yes |
| Interfaces | WLAN | RS485 |
| Protection Class | - |
